DJI AVINOX
Descrizione
Specifiche meccaniche
Telaio
Full Carbon frame Toray T700, 29”, Integrated battery, Tapered, Internal routing, Rear travel 160 mm, 12×148 mm E-Thru, UDH hanger
Forcella
Ohlins RFX38m.3, TTX 18 damper LSC HSC, 29″, Travel 170 mm, 1.5 Tapered, 15×110 mm / Fox 38 Float Factory eMTB+, Air, GRIP X, 29″, Travel 170 mm, 1.5 Tapered, 15×110 mm
Ammortizzatore
Ohlins TTX2Air m2, TTX Damper LSC HSC, 230×65 / Fox Float X2 Factory,EVOL, LSR, HSR, 2 Pos-Lever, 230×65
Serie Sterzo
FSA CRII Dual, 1.5”, Internal routing
Guarnitura
FSA CK745 165mm, 36T MegaTooth
Cambio
Shimano XT RD-M8250 SGS Di2, 12s
Comandi
Shimano XT SW-M8250 Di2, 12s
Freni
Shimano XT BR-M8220, Four piston, Rotor SM-RT86 203 mm / 203 mm
Pacco pignoni
Shimano CS-M8200, 12s, 10/51
Pedali
Alu MTB Full +
Ruote
Radiale WX30, Ratchet 36T
Attacco manubrio
Alu, Barbore 35 mm, Extension S-M frame 35 mm L-XL 50 mm
Piega manubrio
Alu, 780 mm, Barbore 35 mm, Rise 15 mm
Reggisella
Fox Transfer Factory Kashima, Diameter, 31.6 mm, remote
Sella
Selle Royal SRX // Selle San Marco Zero
Coperture
Michelin e-Wild Front&Rear Performance Line, 29″x2.60″, Tubeless ready
Peso
22.4
Taglie
40 – 44 – 48
Diam. ruota [pollici]
29”
Velocità [marce]
12
Specifiche elettriche
Batteria
Avinox 800 Wh (Fixed), weight 3.74 kg
Display
Avinox DP100
Motore
Avinox M2S 2,6 kg
