DJI AVINOX Descrizione
Specifiche meccaniche
Telaio
Front triangle Carbon Toray T700, Rear triangle Alu, 29”, Integrated battery, Tapered, Internal routing, Rear travel 160 mm, 12×148 mm E-Thru, UDH hanger
Forcella
RockShox Psylo Silver RC eMTB, Solo Air, 29″, Travel 160 mm, 1.5 Tapered, 15×110 mm
Ammortizzatore
RockShox Deluxe, Debon Air, 230×65
Serie Sterzo
FSA CRII Dual, 1.5”, Internal routing
Guarnitura
FSA CK745 165mm, 36T MegaTooth
Cambio
Shimano XT RD-M8200 SGS Shadow Plus, 12s
Comandi
Shimano Deore SL-M6200 Rapidfire-Plus, 12s
Freni
Shimano BR-MT420, Four piston, Rotor SM-RT66 203 mm / 203 mm
Pacco pignoni
Shimano CS-M6200, 12s, 10/51
Pedali
Alu MTB Full +
Mozzo anteriore
Radiale J110, 15×110, International, 32h
Mozzo posteriore
Radiale J148, 12×148, International, Microspline, 32h
Cerchi
Radiale W30, eDesign, 622x30c
Attacco manubrio
Alu, Barbore 35 mm, Extension S-M frame 35 mm L-XL 50 mm
Piega manubrio
Alu, 780 mm, Barbore 35 mm, Rise 15 mm
Reggisella
Dropper A1, Diameter 31.6 mm, remote
Sella
Selle Royal SRX // Selle San Marco Zero
Coperture
Schwalbe Nobby Nic, Performance, Addix, 29”x2.60”
Peso
24
Taglie
40 – 44 – 48
Diam. ruota [pollici]
29”
Velocità [marce]
12
Specifiche elettriche
Batteria
Avinox 800 Wh (Fixed), weight 3.74 kg
Display
Avinox DP100
Motore
Avinox M2S 2,6 kg
